Description
Maximum working loads and breaking loads for blocks based on cam strengths.
Sheave Ø(mm)40 mm
Sheave Ø(in)1 9/16 in
Length (mm)112 mm
Length (in)4 1/2 in
Weight (g)157 g
Weight (oz)5.5 oz
Maximum line Ø(mm)10 mm
Maximum line Ø(in)3/8 in
Maximum working load (kg)91 kg
Maximum working load (lb)200 lb
Breaking load (kg)430 kg
Breaking load (lb)950 lb
FootnoteMaximum working loads and breaking loads for blocks based on cam strengths.
