Description
Maximum working loads and breaking loads for blocks based on cam strengths.
Sheave Ø(mm)57 mm
Sheave Ø(in)2 1/4 in
Length (mm)110 mm
Length (in)4 5/16 in
Width (mm)66 mm
Width (in)2 5/8 in
Height (mm)106 mm
Height (in)4 3/16 in
Weight (g)329 g
Weight (oz)12 oz
Maximum line Ø(mm)10 mm
Maximum line Ø(in) 3/8 in
Maximum working load (kg)136 kg
Maximum working load (lb)300 lb
Breaking load (lb)600 lb
Breaking load (kg)272 kg
FootnoteMaximum working loads and breaking loads for blocks based on cam strengths.
