Description
Maximum working loads and breaking loads for blocks based on cam strengths.
Sheave Ø(mm)57 mm
Sheave Ø(in)2 1/4 in
Length (mm)103 mm
Length (in)4 1/16 in
Weight (g)247 g
Weight (oz)8.7 oz
Shackle pin Ø(mm)5 mm
Shackle pin Ø(in)3/16 in
Maximum line Ø(mm)10 mm
Maximum line Ø(in) 3/8 in
Maximum working load (kg)136 kg
Maximum working load (lb)300 lb
Breaking load (kg)340 kg
Breaking load (lb)750 lb
Holding power10:1
FootnoteMaximum working loads and breaking loads for blocks based on cam strengths.
