BEP Smart Battery Hub

The BEP Smart Battery Hub is a complete all in one battery management system. Simplify battery management with remotely activated switches, voltage sensitive relays and emergency parallel functionality all enclosed in an easy to install, Ignition Protected IPX7 enclosure. Monitoring and transmission of battery voltages and full house bank state of charge over NMEA2000 for integration with multi-function displays.

Features and Benefits
IPX7 and Ignition Protected
Monitors and transmits all battery voltages, including house bank state of charge via NMEA2000
Remotely operated switches via analog inputs or CZone®
Ultra low power consumption
Full mechanical override of all switches for safety and servicing

Additional features
Remotely operated emergency parallel switches
Bi-directional VSR functionality with configurable cut in and out voltage thresholds
Monitor up to 2 tank levels, additional battery voltage, temperature or pressure using industry standard sensors
Status LED's for all switch outputs and fault indication
Equipped with advanced core CZone® feature set like load shedding, NMEA2000 switch bank support and many more.
Support for CZone® logic blocks and data switching
USB port allows firmware upgrades and full CZone® system updates including configuration
changes over the NMEA2000 network (no PC or adaptors required)
2 x 10A fused 24 hr house outputs with State of Charge monitoring
Stand-alone functionality for systems without CZone®
