Description
Preassembled module with black powder coated aluminium recessed face plate containing two 113548 Mini Battery Master Switches, Bussmann heavy duty circuit breaker for anchor winch, two 24 hour essential power supply thermal circuit breakers and a 100 amp 'C' Series circuit breaker for the DC main supply. One battery master switch isolates the start battery. The other battery switch parallels the start and house batteries for charging and load applications where required. There is also provision for an additional 'C' Series circuit breaker for other high load applications such as davit winches, toilet treatment systems etc. Supplied with comprehensive circuit breaker label set.
BLA CodeOverall Size mmIntrustion mmProtrusion mmMount Holes mm
BLA Code 113669
Overall Size 239 160 mm
Intrustion 55 mm
Protrusion 35 mm
Mount Holes 3mm r/h
