Description
Specifications
• System pressure -0.3 to +3.0 bar; stationary max. 4.0 bar
• Liquid water/glycol mixture; max. 60% glycol, fresh and saltwater
• Motor service life More than 5,000 hours at nominal voltage 10,000 start/stops. Interchangeable motor
• Motor voltage Nominal 13.6V DC for use between 10-16V, Nominal 27.2V DC for use between 20-32V
• Input power Max. 125W
• Dry running 30 minutes
• Dimensions 244 mm (L) x 120 mm (W) x 150 mm (H)
• Ports Ø 20 mm (3/4″) & Ø 38 mm (1 1/2″)
• Weight 3.0 kg
• Body PPA, glass-fibre reinforced
• Mounting Separate universal bracket for flat surfaces
